China Fully Automatic Printing Machine Dod Printer for Cement Bag (EC-DOD)

Product Description

Fully automatic Printing Machine DOD printer for cement bag(EC-DOD)

DOD, the large character ink-jet printer, was designed and produced by our company in 2013.
Fully Automatic Printing Machine Dod Printer for Cement Bag (EC-DOD)

It is high speed and high efficiency. There are more information about its parameters as follows, such as memory capacity, standard interface, physical features and its printing functions.

Detailed parameters
Memory capacity
Memory storage: up to 200 pieces	Up to 1600 characters per storage
12 dot, 16 dot matrix of characters	Up to 2400 characters
Support 7,9,12,and 16 dot English character and digits
Upgrade special characters according to customer's request
Create 32*2048 graphic dot matrix with customer's demand
Communicate with PC to change printing text
Standard interface
Photocell /synchronized interface	USB
Interface to external alarm	RS-232
Physical feature
Industrial-grade stainless steel
Installation	Desktop
Continuous ink supplying, free of external air source
Operating temperature	5-45ºC
Power supply	AC 100-240V 50/60Hz
Power	150W
Parameters
Printing lines	4 lines(based on 7 dot English character)
Print head quantity	Up to 2 print head(16 dot)
Printing height	8mm-64mm(16 dots print head)
Printing distance	5mm
Printing speed	100m/min
Printing direction	Horizontal and vertical
Printing functions
Time(accurate to the seconds)
Date(any combination format)
External communication and remote control function
Capable of printing on two different production lines simultaneously
Up to 32 bit serial number
Logo
Capable of installing Asian pinyin characters input method
Capable of conversing intelligent picture
