High Performance 1-4 Lines Batch Expiry Date Cable Aluminum Cans Inkjet Coding Machine

Product Description

High Performance 1-4 Lines Batch Expiry Date Cable Aluminum Cans Inkjet Coding Machine

(PM-100)

Product Description:
Ink-jet printer is an un-contiguous marking system controlled by single chip. By controlling inner gear pump or providing compressed gas from machine exterior, it puts press on the inks in the system, emits inks by way of several dozen UM nozzle. Electric ink drop deflects in deflecting electric field formed from deflecting electrode, emits from spray nozzle, strike different positions on the product surface, forms required kinds of characters, patterns and other marks.
High Performance 1-4 Lines Batch Expiry Date Cable Aluminum Cans Inkjet Coding Machine

High Performance 1-4 Lines Batch Expiry Date Cable Aluminum Cans Inkjet Coding Machine

Besides this, our machine has its own advantages:
1. It can print trade mark, numbers, logos and other information on products with various measurements.
2. It can work with a high efficiency for a long time, under common even bad production environment.
3. It has a powerful function of employment and interlinkage.
4. It can connect with computer, can choose font in computer randomly.
5. The industry-protection grade is high, it can work under a humid and high-temperature industry environment.
6. The nozzle is airproof, so it can protect burner cap out of the influence of powder.
7. It is widely used, the mark is clear and permanent.
8. The price of our inks is lower than the leading brands, as a consumable, it is an important factor for inkjet printer.

Technical Date:

Model	PM-100B
Fuselage	Stainless steel 304, surface process
Voltage	220V±20% 50HZ 100VA
Pressure	Normal operation under pressure up to 4.48bar, under the fault conditions as high as 6.2bar.
Nozzle size	38*170.1mm
Spraying distance	Trumpet: 3.5mm Medium: 10mm spray nozzle
Jet printing speed	2m/s (5 * 7 dot matrix)
Jet printing dot matrix	32 * 140 in any dot matrix, digital, Chinese characters, letters, charts, etc.
Spray into the number	1-4 lines, can be sprayed 34 lines of 1 points high pattern, or four lines of 7 points, or 6 lines of 5 points high character.
Character height	Minimum character height of 1.1mm, maximum height of 11.2mm, up to 24 points
Meter function	Arbitrary unit meter
Adapted ink	Red, black, blue, green, yellow, high adhesion, high temperature, invisible ink, etc. (this machine can not use the pigment ink)
Ink value consumption	500ml printing (5 * 7 dot matrix digital) about 60,000,000 dot matrix
Temperature	-5ºC--45ºC
Humidity	50--80RH% No dew
Spray printing function	Bold characters up to 9 times, characters with rotating function: spray print height, width and delay can be automatically adjustable frequency, date, and time between the word format: fixed and variable text, size, can write character in real time clock function, can jet printing to seconds; USB pattern call / ink jet printer data, backup parameters reduction function / software system upgrade; features a serial number, with hexadecimal counting function a lot number and the counting function, reverse jet printing function, timing functions; date and event format options for a flexible, automatic date calculation.

Application Fields:
Application materials: Perfect Laser's inkjet printer is widely used for paper printing, glass bottles printing, plastic bottles printing, metal printing, medicine box printer, plastic bags printing, cartons printing, paper bags printing, electronic products printing, labels printing, nylon printing, ABS/PVC/PC printing, rubber printing, resin printing, ceramic printing, etc.

Technical Data:

Machine Type	Inkjet Printer
Model Number	PM-100	PM-200	PM-300
Print lines	1_3 lines	1_4 lines	1_6 lines
Advantage	LCD+press keyboard screen	LCD+press keyboard screen	LCD touching screen
Print herght	1-15mm (adjustable)
Print distance	0--4cm
Print speed	4.5m/s(5× 7pixel)
Interface	In Chinese & English, with editing function
Store Information	40 pcs of jet printing information
Jet ink Available	Black, blue, red and other color ink
Font Widened	1~9 times
Print Content	Numbers, Chinese character, Letter, Logo, Serial numbers, Random numbers etc. with in 32× 2560pixel.
Fixed length print Function	Any unit, any length.

After- Sale Service:
1> All of our machine will be full-checked by our quality control department before the shipment. We make sure that customers
will be get good products from us. and all of our machine with a 12 months quality guarantee period.
2> We will enclose an "Instruction Book", "Operation Manual" and "Training Video" (in English version) to you, which is easily understood and handle by the
customer.
3> We will offer plenty of online supports, by email, video, telephone and fax.
4> Our engineer can make a door-to-door instruction training service.
High Performance 1-4 Lines Batch Expiry Date Cable Aluminum Cans Inkjet Coding Machine

Working Video :
Perfect Laser-Industrial Inkjet Printing Machine :https://youtu.be/FCn9471FmTc
