20 30L Pure Alcohol Filling and Weighting Machine
Product DescriptionParameterBesuitable to the material bucket-packing material with good fluidity for semi-auto filling.The machine is a new type filler integrating the electronic scaling technology, machinery, electronics, instruments on a whole. Using the scaling way to monitor in time the curren......
Send Inquiry
Product Description
Product Description
Parameter
Besuitable to the material bucket-packing material with good fluidity for semi-auto filling.The machine is a new type filler integrating the electronic scaling technology, machinery, electronics, instruments on a whole. Using the scaling way to monitor in time the current filling quantity and feedback it to the controlling instrument, the controlling instrument outputs the controlling signal for the fast, slow filling per the setting data, realizing the fast and accurate filling for the fairly large filling sizes.
Note:
This machine is filling head is drive by step motor, and filling nozzle could be rise with the liquid level. And machine with fix bottle and barrel position function.
Model: FY-CZ-50
filling precision : ±0.2-0.5%
Filling nozzle: 1pcs
Conveyor belt length: 1M
Range of filling :5-50L
Production capacity :12 barrels/min(5L/barrel)
Entrance pressure :0.2~0.5(Mpa)
Air pressure :0.5-0.7(Mpa)
Power source :AC380(V) 50(Hz) 3 phases
Total power : 35W
Dimension:175*98*190cm, Weight:160kg
Main part
Spare part:
Swich,1 pcs. Filling nozzle seal: 3 pcs. Fill tube: 1.5 metres.
Air tube joint: 5 pcs
Package & Shipping
Our Service
After Sales Service
The above machine which we supply it to you, we can give you one years after sales warranty, we can also send our engineer to you factory to install this equipment and train your staff, but the Buyer should pay the round air ticket cost and arrange the hotel accommodation as well as the means for Seller's engineer. We will send some free set of spare parts for you change it.
Payment terms:
30% deposit by T/T before production, 70% balance should be paid by T/T before shipment. but we also accept L/C.
Package:
Standard wooden Case Packing
Shipment terms:
We usually take FOB, but we can also accept EXW,CIF,CNF.
Frequently Asked Questions and Answers:
Q1. Your company is a trading company or manufacturer / factory?
Our company is a manufacturer / factory. Our factory is in Bai Yun District, Guangzhou, China. Welcome to visit our factory at any time !
Q2. What machines can your company produce?
We can produce all kinds of sachets packing machines, bottles / jars filling machines, sealing machines, capping machines, labeling machines and coding machines, for foods, drinks, cosmetics, chemicals, medicines, agricultural products, etc. We can also assemble our machines to be various automatic production lines. And, our machines can be customized, we can make machines according to our clients' requests and their products.
Q3. What materials of your machines are made of ?
According to our clients' different requests, our machines are made of high class stainless steel 304, stainless steel 316 or 316 L, carbon steel, Al alloy, etc.
Q11. Do you provide the maintenance service?
Yes, we provide maintenance services, because regional difference, we can provide you the services by Email, telephone, express or internet online tools.
Company Info
Guangzhou Change Machinery Co.,Ltd. is a professional supplier of sachets packing machines, bottles/jars filling machines, labeling machines, sealing and capping machines, and various customized production lines, with reasonable price, reliable quality, considerate pre- and after sale services.
We value our customers feedback with great attention and we always explore new technologies to improve our products and our services to meet our customers' needs. Our Company Motto:"We Change, we get Chance; We never change our faith!" Based on this principle, we aim at a pleasant and mutual beneficial business relationship with our customers and partners all over the world.
Parameter
Besuitable to the material bucket-packing material with good fluidity for semi-auto filling.The machine is a new type filler integrating the electronic scaling technology, machinery, electronics, instruments on a whole. Using the scaling way to monitor in time the current filling quantity and feedback it to the controlling instrument, the controlling instrument outputs the controlling signal for the fast, slow filling per the setting data, realizing the fast and accurate filling for the fairly large filling sizes.
Note:
This machine is filling head is drive by step motor, and filling nozzle could be rise with the liquid level. And machine with fix bottle and barrel position function.
Model: FY-CZ-50
filling precision : ±0.2-0.5%
Filling nozzle: 1pcs
Conveyor belt length: 1M
Range of filling :5-50L
Production capacity :12 barrels/min(5L/barrel)
Entrance pressure :0.2~0.5(Mpa)
Air pressure :0.5-0.7(Mpa)
Power source :AC380(V) 50(Hz) 3 phases
Total power : 35W
Dimension:175*98*190cm, Weight:160kg
Main part
| PLC | Taiwan Delta |
| Balance | Taiwan Songzhan or Guangzhou KUNLUN |
| Operate panel | China TouchWin |
| Cylinder | Taiwan Airtac |
| Step Motor | Shanghai OTG |
| Low voltage protector | France Schneider |
| Stable relay | France Schneider |
Swich,1 pcs. Filling nozzle seal: 3 pcs. Fill tube: 1.5 metres.
Air tube joint: 5 pcs
Package & Shipping
Our Service
After Sales Service
The above machine which we supply it to you, we can give you one years after sales warranty, we can also send our engineer to you factory to install this equipment and train your staff, but the Buyer should pay the round air ticket cost and arrange the hotel accommodation as well as the means for Seller's engineer. We will send some free set of spare parts for you change it.
Payment terms:
30% deposit by T/T before production, 70% balance should be paid by T/T before shipment. but we also accept L/C.
Package:
Standard wooden Case Packing
Shipment terms:
We usually take FOB, but we can also accept EXW,CIF,CNF.
Frequently Asked Questions and Answers:
Q1. Your company is a trading company or manufacturer / factory?
Our company is a manufacturer / factory. Our factory is in Bai Yun District, Guangzhou, China. Welcome to visit our factory at any time !
Q2. What machines can your company produce?
We can produce all kinds of sachets packing machines, bottles / jars filling machines, sealing machines, capping machines, labeling machines and coding machines, for foods, drinks, cosmetics, chemicals, medicines, agricultural products, etc. We can also assemble our machines to be various automatic production lines. And, our machines can be customized, we can make machines according to our clients' requests and their products.
Q3. What materials of your machines are made of ?
According to our clients' different requests, our machines are made of high class stainless steel 304, stainless steel 316 or 316 L, carbon steel, Al alloy, etc.
Q11. Do you provide the maintenance service?
Yes, we provide maintenance services, because regional difference, we can provide you the services by Email, telephone, express or internet online tools.
Company Info
Guangzhou Change Machinery Co.,Ltd. is a professional supplier of sachets packing machines, bottles/jars filling machines, labeling machines, sealing and capping machines, and various customized production lines, with reasonable price, reliable quality, considerate pre- and after sale services.
We value our customers feedback with great attention and we always explore new technologies to improve our products and our services to meet our customers' needs. Our Company Motto:"We Change, we get Chance; We never change our faith!" Based on this principle, we aim at a pleasant and mutual beneficial business relationship with our customers and partners all over the world.
