Filling Line Machine Developed on The Basis of Digesting Advanced Technology
1) This filling line includes the plastic bottle washer, negative pressure bottle water filler, plastic cap capper, and conveyor, and other packing line machines. 2) The filling line machines are developed on the basis of digesting and absorbing advanced technology introducing from abroad and is wi......
Send Inquiry
Product Description
1) This filling line includes the plastic bottle washer, negative pressure bottle water filler, plastic cap capper, and conveyor, and other packing line machines.
2) The filling line machines are developed on the basis of digesting and absorbing advanced technology introducing from abroad and is with international advanced level.
3) It is mainly used for filling non carbonated drink, like mineral water, drinking water, other liquid packed in plastic bottle. The filling way is negative pressure.
4) It adopts the high quality of stainless steel 304 material, meets the requirements of food grade.
5) It is advanced in construction, steadily in performance, safe in operation, easy in maintenance high in production efficiency, and the speed can be regulated infinitively.
6) The filling machine is the ideal choice for drink factories of small and middle size.
Main Technology data:
| Model | GFP-12 |
| Production Capacity | 0-2000b/h (500ml) |
| Filling head | 12 |
| Work principle | Negative pressure |
| Automatic type | Automatic |
| Material | SUS304 |
| Bottle standard | Plastic bottle |
| Applicable bottle diameter | 60-100mm |
| Applicable bottle height | 160-320mm |
| Standard | Electromagnetic speed regulation |
| Power | 1.1kw |
| Overall Dimensions | 1000×900×1800 mm |
| Weight | 450kg |
Min order: 1 Set
Port: ShangHai Port
Payment term: L/C, T/T, WESTERN UNION
30% deposit by T/T, 70% balance by T/T before shipment.
Packing detail: Wooden case package or blanket cloth package.
Delivery time: 20-25 days after 30% T/T payment.
Delivery time:
30 days upon deposit and approval to the bottle drawing.
Payment term:
For machine: 30% T/T deposit within five days after the contract is signed against invoice of the seller. The balance of 70% will be paid before shipment.
Guarantee:
We response for 12 months warranty for the machine, however, it without any human conduct. And provide one-year free spare part for client. And send engineer to client's company, help install the machine, teaching their staff operate the machine and also, we do have a private school which help our client sending their staff to china, help them training.
