Automatic High Speed Pouch Making Machine (ZHP- 600B )
Features:Suitable for various laminated films.All the parameters are diaplayed in CRT real time. The speed, bag length, temperature, counting, punching, multiplying delivery and delivery amount of finished products, etc, can be pre-set.Bag length is controlled by a.c. double servo-system, with super......
Send Inquiry
Product Description
Features:
- Suitable for various laminated films.
- All the parameters are diaplayed in CRT real time. The speed, bag length, temperature, counting, punching, multiplying delivery and delivery amount of finished products, etc, can be pre-set.
- Bag length is controlled by a.c. double servo-system, with super quality and high efficiency.
- Automatic alarm for unwinding tension, middle tension, color sign loss and super high temperature.
- New type lifting 6 multiplying delivery function.
- Automatic unwinding tension control and photo-electric deviation rectification.
| Roll size: | Max.Diameter:Φ600mm Max.Width: 1240mm | |
| Bag-making speed: | 30~180cpm(≈36m/min) | |
| Bag-making form and size | Longitudinalbag-making | Transverse bag-making |
| L:Bag Length | Max.500mm,Multiplyingy delivery at aultra-length | 50-600mm, 1-5 line array |
| W:Bag Width | 85-600mm, 1-5 line array | Max. 580mm |
| S1:Bottom sealing | Max. 80mm | |
| S2:Side sealing | Max. 25mm | |
| S3: Bottom sealing | Max. 25mm | |
| S4: Side sealing | Max. 40mm | |
| Total Output | 35kw | |
| Pneumatic source | 0.6Mpa(6kg/cm2) | |
| Cooling water | 5L/min | |
| Weight | 5000kg | |
| Overall dimension | 8500x2400x1865(mm) LxWxH | |
