Flat and Square Paper Bag Machine (LQFS 1600)

Product Description

Instructions
LQFS1600 Flat&Square Paper Bag Machine is a coned-bottom paper processing equipment which combines international advanced technology and demands at home and abroad, and is capable of gelatinizing and patching on original color or printed roll paper at one time with the same machine, applying side glue, drawroll, cutoff, gelatinizing at bottom, shaping bag, count collection. The construction of the whole machine is reasonable, compact. It is convenient to adjust, controlled by high speed CPU, and equipped with touch screen display. With servo motor controlling bag production speed, it can produce with single channel or dual channel (produce two bags at one time), with max. speed as high as 1000PCS/min. It is an ideal choice in replacing imported equipment.

Parameters

LQFS 1600 LQFS 1600 Machine Specifications
Single Stream	Face Width (w/o gusset)	1.5 to 14.5 inches	39 to 368 mm
	Face Width (with gusset)	2 to 12.5 inches	51 to 317 mm
	Total Gusset	5 to 5 inches	13 to 127 mm
Dual Stream	Face Width (w/o gusset)	1.5 to 7 inches	39 to 177 mm
	() Face Width (with gusset)	2 to 5.75 inches	51 to 146 mm
	Total Gusset	5 to 3 inches	13 to 76 mm
Cutoff Length Range		4 to 11.5 inches	102 to 292 mm
Maximum Web Width		30 inches	762 mm
Maximum Roll Diameter		47.2 inches	1200 mm
Paper Substrate Range		20 to 40 pounds	30g/m² to 65g/m²
Minimum Seam Overlay		625 inches	16 mm
Minimum Former Flap = Seam Overlay + Seam Offset		1 inches	25 mm
